Automatic Weighing 1kg 5kg Bag Packing Machine

Automatic Weighing 1kg 5kg Bag Packing Machine Made in China

Technical data:

Type:Multi-Function Packaging Machine

Machine material:Food Grade SS304/316

Weighing accuracy:≥99.5%

Capacity: 20-50 Bag/Min

Function:Auto-Weight-Form-Fill-Seal

Bag size can make:W:80-250mm L:30-400mm

Max Film Width:520mm

Weight (KG):900

电压:220/50HZ

Dimension(L*W*H):(L)1488*(W)1080*(H)1490mm

Units ofAutomatic Weighing 1kg 5kg Bag Packing Machine:

Mandatory : 420 host ,powder metering head, screw feeder

Optional :

Finished product conveying device .

Imported PLC computer control system, Chinese/English touch screen operating system, clearly display each working state and operation instructions.

Adopt high precision film transport system, film transport is stable, with photoelectric automatic positioning tracking system, high positioning accuracy.

Intelligent digital temperature control system, stable temperature control, toothed sealing device, to ensure a firm sealing.

With automatic fault alarm display function, such as low temperature, no packaging film, colorless belt, no material, uniform fault, colorless signal, glass protective door when opened, automatic alarm or stop function.

This machine can automatically complete the whole packing process of measuring, feeding, bag-making, date printing and finished product output when matched with measuring device.
